HT320T Skid Steer Loader
TheHTS320T Skid Steer Loader Maximum lifting height is up to 834.64in and keeps the bucket level to the ground.Lift arm, bucket and attachments are operated separately.
.jpg)
RATO ENGINE
This skid steer loader is powered by a premium RATO R420 engine with up to 9.7KW of power for powerful yet fuel-efficient operation and superior heat distribution. Bid farewell to grating vibrations, savor flawless functioning, and anticipate its longevity.
EASY OPERATION
Use the handy joysticks to effortlessly adjust the speed, direction, and lifting height. For simple and accurate movement, this small skid steer is suitable for both inexperienced and seasoned landscapers.
AUTOMATIC LEVELING SYSTEM
Maximum lifting height is up to 834.64in and keeps the bucket level to the ground.Lift arm, bucket and attachments are operated separately.
EASY MAINTENANCE
The front cover plate is easy to open and supported by double rods for easy maintenance and inspection inside the cabin.
HIGH-PERFORMANCE TRACKS
The lower vehicle adopts triangular track structure, which makeswalking more stable.
FLEXIBLE OPERATION
HIGHTOP skid steer is ability to operate the lifting arm, bucket, and attachments independently enhances flexibility, precision, and control.
.jpg)
.jpg)
|
Model:HT320T |
||||
|
Max working height |
2120mm |
Engine |
RATO Engine R420 |
Briggs & Stratton Engine 13.5HP |
|
Max pin height |
1865 mm |
Rated Power (KW) |
9.7Kw/3600rpm |
10Kw/3600rpm |
|
Max Dumping height |
1405 mm |
Rotating speed (rpm) |
3600 |
3600 |
|
Max Dumping distance |
575mm |
Noise (Db) |
≤95 |
≤95 |
|
Max Dumping Angle |
37° |
Hydraulic System |
||
|
Total height |
1350 mm |
Pressure (Mpa) |
0-17 |
0-17 |
|
Ground clearance |
121 mm |
Flow rate |
0-18L |
0-21.6L |
|
Wheel base |
|
Operating Load |
250 Kg |
250Kg |
|
Overall length without bucket |
1495 mm |
Bucket Capacity |
0.15m³ |
0.15m³ |
|
Total width |
1021 mm |
Max Lifting Force |
360 Kg |
360 Kg |
|
Bucket width |
1080mm |
Travel Speed |
0-4.5Km/h |
0-4.5Km/h |
|
Total length with bucket |
2245 mm |
Operating Weight |
830 Kg |
830 Kg |
|
overall length without the bucket after folding the pedal.
|
1990 mm |
Oil |
||
|
Fuel tank |
7L |
7L |
||
|
|
|
Engine oil |
1.7L |
1.7L |
|
|
|
Hydraulic tank |
37L |
37L |
