HT360W Skid Steer Loader
HTS-360W small wheeled skid steer loader is a kind of versatile, compact and flexible construction machinery.
Wheeled skid steer loader utilizes the difference in linear speed between two wheels to realize vehicle steering, this steering mode makes the loader able to realize in-situ steering in a narrow space, with a very small steering radius, which is especially suitable for narrow field operation.
Chassis: wheeled walking mechanism, all-wheel drive, with good maneuverability and throughput, can adapt to a variety of complex terrain.
Engine: Output power is 8.5KW/3600rpm, providing power support for the work of the loader, featuring strong power and good fuel economy.
Working device: It can be equipped with many kinds of working devices, such as bucket, sweeper, milling machine, crushing hammer, forks, etc. The action of the working device is controlled by the hydraulic system, which can realize various working functions such as shoveling, digging, crushing, sweeping, etc.
performances |
Rated loading capacity |
kg |
220 |
Bucket volume |
m³ |
0.09 |
|
Maximum lifting force |
kg |
375 |
|
Working speed |
km/h |
0-6.5 |
|
Rated pressure |
Mpa |
17 |
|
Lifting time |
S |
4.5 |
|
Lowering time |
S |
3.5 |
|
Tipping time |
S |
1.5 |
|
Working weight |
kg |
720 |
|
Engine |
Engine name |
RATO Engine |
|
Model |
R420D |
||
Type of engine |
Gasoline Single Cylinder |
||
Output power |
8.5KW(15hp)/3600rpm |
||
Fuel consumption |
L/h |
≤4.1 |
|
Starting method |
electric start |
||
quantitative |
Fuel tank |
L |
6.7 |
Engine oil |
L |
1.1 |
|
Hydraulic oil tank |
L |
25 |
|
Overall Dimension |
Length x Width x Height |
mm |
2400X1030X1330 |
Packing size (wooden box) |
Length x Width x Height |
mm |
1700x1050x1350 |
