HT-10E 1ton Mini Excavator
The HT-10E 1-ton micro excavator for sale is an ultra-narrow powerhouse designed for high-precision landscaping and indoor demolition in confined spaces. Featuring an intuitive control system and low fuel consumption, this micro excavator ensures maximum efficiency and a superior ROI for rental fleets and professional contractors. Inquire today for factory-direct wholesale pricing and comprehensive B2B support on our reliable compact machinery.
Abandoning mechanical operation and adopting two side pilot operation, it has a comfortable feel, smooth movement, high efficiency, and makes it easier for users to operate and more agile in use.
The body is designed with a flip up cover, allowing users to easily and quickly open the seat cover for maximum maintenance and repair.
| HT10E Mini Excavator — Parameter Table | |
|---|---|
| Overall Dimensions (Unit: mm) | |
| Model | HT10E |
| Transport Length | 2200mm |
| Total Width | 930mm |
| Upper Width | 805mm |
| Overall Height (Cab Roof) | 2195mm |
| Standard Track Plate Width | 180mm |
| Track Gauge | 750mm |
| Shovel Height Above Ground | 110mm |
| Depth of Excavation of Bulldozer | 200mm |
| Tail Turning Radius | 795mm |
| Track Ground Length | 890mm |
| Track Length | 1235mm |
| Working Range (Unit: mm) | |
| Maximum Digging Height | 2605mm |
| Maximum Unloading Height | 1750mm |
| Maximum Digging Depth | 1745mm |
| Maximum Digging Distance | 2915mm |
| Minimum Turning Radius | 1405mm |
| Maximum Height at Minimum Turning Radius | 2060mm |
| Performance Parameters | |
| Weight | 1000kg |
| Bucket Capacity | 0.02m³ |
| Working Device Form | backhoe |
| Climbing Capacity | 30° |
| Main Components | |
| Engine | Koop / Briggs & Stratton |
| Power | 7KW / 10.1KW |
| Main Valve | Tengfei |
