HT15 1.5T Mini Excavator
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
DESCRIPTION
Double cylinder water cool engine, hydraulic joystick
HT15 1.5T Mini Excavator Advantage
1.5 ton mini hydraulic excavator is with compact design, and with low oil consumption, it is suitable to be used for works, small projects, in garden, farmland, municipal works, vegetable greenhouse and digging trench. It is with small engine, simple design and easy to maintain.
1) Simple structure and compact design ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Give full consideration to reduce the working oil consumption, to obtain maximum efficiency in all kinds of work site operation.
4) Auger, grab, hydraulic hammer, narrow bucket can be installed on this excavator, efficient and wide-range use.
5) Small invest, quick return.
1) Simple structure and compact design ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Give full consideration to reduce the working oil consumption, to obtain maximum efficiency in all kinds of work site operation.
4) Auger, grab, hydraulic hammer, narrow bucket can be installed on this excavator, efficient and wide-range use.
5) Small invest, quick return.
Parameter
HT15 1.5T Mini Excavator Parameter
| Model | HT15-1 | HT15-2 | HT15-3 | HT15-4 | HT15-5 | Model | HT15-Li |
| Vehicle Weight | 1500KG | 1500KG | 1500KG | 1500KG | 1500KG | operating weight | 1500KG |
| Standard bucket capacity | 0.04M3 | 0.04M3 | 0.04M3 | 0.04M3 | 0.04M3 | bucket capacity | 0.04M3 |
| Engine model | KOOP 192 | B&S 25T2 | KOOP 292 RATO |
KUBOTA D722 | B&S 3864 | Battery | 72V/48V |
| Rated power/speed | 7KW | 10.2KW | 12KW | 12KW | 17.5KW | Power | 4KW |
| System pressure | 9Mpa | 16Mpa | 16Mpa | 16Mpa | 16Mpa | Battery voltage | 72V/48V |
| Rotary speed | 11RMP | 11RMP | 11RMP | 11RMP | 11RMP | Battery capacity | 135Ah |
| Maximum climbing angle | 35° | 35° | 35° | 35° | 35° | Battery weight | 100KG/pc |
| Walking speed (high/low speed) | 3 5Km/h | 3 5Km/h | 3 5Km/h | 3 5Km/h | 3 5Km/h | working time | ＞15H |
| Fuel tank volume | 18L | 18L | 18L | 18L | 18L | Track length | 1090 |
| Wheel spacing | 800mm | 800mm | 800mm | 800mm | 800mm | Platform ground clearance | 380 |
| Total tracked | 1220mm | 1220mm | 1220mm | 1220mm | 1220mm | Rear-end swing radius | 733 |
| Platform clearance | 375mm | 375mm | 375mm | 375mm | 375mm | Width of chassis | 946 |
| Chassis width | 980mm | 980mm | 980mm | 980mm | 980mm | Width of track | 180 |
| Track width | 180mm | 180mm | 180mm | 180mm | 180mm | Hight of track | 320 |
| Maximum ground excavation radius | 2900mm | 2900mm | 2900mm | 2900mm | 2900mm | Over length | 2550 |
| Maximum excavation depth | 1850mm | 1850mm | 1850mm | 1850mm | 1850mm | Machine height | 1330 |
| Maximum excavation height | 2450mm | 2450mm | 2450mm | 2450mm | 2450mm | Max. digging radius | 2400 |
| Maximum Unloading Height | 1850mm | 1850mm | 1850mm | 1850mm | 1850mm | Max. digging depth | 1650 |
| Maximum vertical digger depth | 1750mm | 1750mm | 1750mm | 1750mm | 1750mm | Max. digging height | 2490 |
| Minimum radius of rotation | 1550mm | 1550mm | 1550mm | 1550mm | 1550mm | Max. dumping height | 1750 |
| Maximum lifting height of shovel | 150mm | 150mm | 150mm | 150mm | 150mm | Max. vertical depth | 1400 |
| Maximum depth of excavation of a bulldozer | 180mm | 180mm | 180mm | 180mm | 180mm | Min. gyration radius | 1190 |
| Maximum depth of excavation of a bulldozer | 180mm | 180mm | 180mm | 180mm | 180mm | Max.lifting height of dozer blade | 325 |
Product Picture
.jpg)
.jpg)
.jpg)
