HT15Pro-Li 1.5T Electric Mini Excavator
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Technical Parameter
| HT15PRO-Li | |
| Dimensions | |
| Transport length | 2300mm |
| Total width | 930mm |
| Upper width | 990mm |
| Overall height (cab roof) | 2270mm |
| Standard track plate width | 180mm |
| Track gauge | 750mm |
| Shovel height | 110mm |
| Shovel digging depth | 200mm |
| Tail turning radius | 800mm |
| Track ground length | 890mm |
| Track length | 1235mm |
| Working Range | |
| Maximum digging heighta | 2690mm |
| Maximum unloading heightb | 1825mm |
| Maximum digging depthc | 1710mm |
| Maximum digging distance | 2920mm |
| Minimum turning radius | 1500mm |
| Maximum height at minimum turning radius | 2110mm |
| performance parameter | |
| Working mass | 1000kg |
| Bucket capacity | 0.02m³ |
| Form of working device | backhoe |
| Climbing capacity | 30° |
| Main parts | |
| motive power | Li battery |
| Battery | 72V150Ah |
| Motor power | 6.5KW |
| Motor model | Permanent magnet synchronous motor |
Product Introduction
